Hãng | Asus | |||||||||
Loại | Bo mạch chủ - Dành cho máy bàn (PC) | |||||||||
Mainboard |
|
|||||||||
Socket | LGA 1700 | |||||||||
CPU hỗ trợ | Hỗ trợ Intel Core 12th, 13th Processors | |||||||||
Chipset | Intel B760 | |||||||||
Bus RAM Hỗ Trợ | 4 x DIMM slots, maximum 128GB, DDR5 7800(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/5600 /5400/5200/5000/4800 MHz Non-ECC, Un-buffered memory | |||||||||
Khe cắm mở rộng | Intel 13th & 12th Gen Processors - 1 x PCIe 5.0x16 slot (supports x16 mode) Intel B760 Chipset - 1 x PCIe 3.0 x16 slot (supports x4 mode) - 2 x PCIe 3.0 x1 slots |
|||||||||
Ổ cứng hỗ trợ | Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports* Intel® 13th & 12th Gen Processors - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel® B760 Chipset - M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 ) - M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 ) - 4 x SATA 6Gb/s ports * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10. |
|||||||||
Cổng kết nối (Internal) | Fan and Cooling related - 1 x 4-pin CPU Fan header - 1 x 4-pin CPU OPT Fan header - 1 x 4-pin AIO Pump header - 4 x 4-pin Chassis Fan headers Power related - 1 x 24-pin Main Power connector - 1 x 8-pin +12V Power connector - 1 x 4-pin +12V Power connector Storage related - 3 x M.2 slots (Key M) - 4 x SATA 6Gb/s ports USB - 1 x USB 3.2 Gen 2 connector (supports USB Type-C® ) - 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports - 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous - 3 x Addressable Gen 2 headers - 1 x Aura RGB header - 1 x Front Panel Audio header (AAFP) - 1 x 20-3 pin System Panel header with Chassis intrude function - 1 x Thermal Sensor header - 1 xThunderbolt™ (USB4®) header |
|||||||||
Cổng kết nối (Back Panel) |
- 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) - 1 x USB 3.2 Gen 2 port (1 x Type-A) - 6 x USB 3.2 Gen 1 ports (6 x Type-A) - 1 x DisplayPort - 1 x HDMI® port - 1 x Wi-Fi Module - 1 x Intel® 2.5Gb Ethernet port - 5 x Audio jacks - 1 x Optical S/PDIF out port - 1 x BIOS FlashBack™ button - 1 x Clear CMOS button |
|||||||||
Cổng LAN | Intel® 2.5Gb Ethernet ASUS LANGuard | |||||||||
Kích cỡ | Micro ATX Form Factor: 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
